Fire Glass

Your Partner in Fire Rated Glass Solutions

product-banner

At Fast Glass Processing, we pride ourselves on having a dedicated team of highly trained staff committed to meeting our customers’ needs. Our office personnel possess extensive knowledge in fire-rated glass, ensuring we provide exceptional technical advice on various glass types for the supply and fit industry.

We specialize in producing both single glazed and double glazed fire-rated units tailored to your specific requirements. Our offerings include:

benefits-icon
30/0 and 60/0 clear/wire fire rated glass
benefits-icon
30/30, 60/30, and 60/60 insulated fire rated glass
benefits-icon
Fire Screens: Designed to enhance safety in your environment.
benefits-icon
Fire Rated Double Glazed Units: Combining safety with energy efficiency.
logo
card-text-image
C730 7.2MM PYROGUARD
PYROSTEM CLEAR WIRED
WHICH TO CHOOSE?

C730 7.2MM PYROGUARD

Pyroguard EW30 impact is perfect for indoor and outdoor use. They are fabricated in large sheets, double-sided fire resistance that can be cut to size offering a cost-effective solution.

Key Features
  • EW30 fire classification
  • 2B2 impact classification
  • Interior and exterior use
  • Double-sided fire resistance
  • UV stability
  • Steel & timber applications
Suitable Application
  • Can be used in fire tested timber and steel systems
Technical Information
Fire Classification EW30
Impact Classification 2(B)2
Light Transmission 87%
Sound reduction 33 dB
U Value 5.1 W/m2 K
UV Stability Yes
Fire Classification EW30
Nominal Thickness 7mm
Thickness Tolerance -0.6 / +0.8 mm
Weight 17kg per m2
Temperature Range -20 / +140 °C

PYROSTEM CLEAR WIRED

Glass is an entry-level cuttable, wired fire-rated glass. Pyrostem is typically used in refurbishment projects which demand an economical glass with the appearance and performance of Georgian polished wired.

KEY FEATURES PYROSTEM CLEAR WIRED
  • Fire-resistant E30/E60
  • Glazing integrity criterion EN 572-3
  • Cuttable
  • Can be used internally and externally
SUITABLE APPLICATION
  • Can be used in fire tested timber and steel systems.
Technical Information
Resistance to fire EW30
Reaction to fire A1
Pendulum body impact resistance 3B3
Wind, snow, permanent and imposed load resistance 7.2 mm
Direct airborne sound reduction 31 (-2; -3) dB
Thermal properties 5.7 W/m2K
Radiation properties: Light transmission/Light reflection 87.8% / 7.6%
Solar properties:Transmittance/Reflectance 80.7% / 6.9%
MANUFACTURER/ PRODUCT THICKNESS (mm) INTERIOR EXTERIOR FIRE RATING CERTIFICATE NO DB RATING SAFETY RATING
AGC
Pyrobelite 7 7.9 icon icon 30/0 CF377 34 3B3
Pyrobelite 9EG 12.06 icon icon 30/0 CF377 35 1B1
Pyrobelite 12 12.3 icon icon 60/0 CF377 36 2B2
Pyrobel 16 17.3 icon icon 60/30 CF377 39 2B2
Pyrobel 16EG 21.1 icon icon 60/30 CF377 39 1B1
Pyrobel 25 26.6 icon icon 60/60 CF377 40 1B1
Pyrobel 25EG 30.4 icon icon 60/60 CF377 43 1B1
PILKINGTON
Pyrodur® 7mm EW30 7 icon icon 30/0 CF328 34 3B3
Pyrodur® 10mm EW60 10 icon icon 60/0 CF328 35 2B2
Pyrodur® 11mm EW30 11 icon icon 30/0 CF328 37 1B1
Pyrodur® 13mm EW60 13 icon icon 60/0 CF328 38 1B1
Pyrodur® 14mm EW30 14 icon icon 30/30 CF328 38 2B2
Pyrodur® 15mm EW30 15 icon icon 30/30 CF328 38 2B2
Pyrodur® 18mm EW30 18 icon icon 30/30 CF328 38 1B1
Pyrodur® 23mm EW60 23 icon icon 60/60 CF328 41 1B1
Pyrodur® 27mm EW60 27 icon icon 60/60 CF328 41 1B1
PYROGUARD
Pyrostem (GWPP) 7 icon icon 60/0 CF581 31 3B3
Fire Door 60 9 icon icon 60/0 CF257 33 2B2
Pyroguard 7.2 icon icon 30/0 CF257 33 2B2
Pyroguard 11.4 icon icon 60/0 CF257 35 2B2
Pyroguard Insulation 15 icon icon 60/30 CF437 38 1B1
Pyroguard Insulation 19 icon icon 60/30 CF437 39 1B1
Pyroguard Insulation 23 icon icon 60/60 CF437 40 1B1
Pyroguard Insulation 27 icon icon 60/60 CF437 42 1B1

Commitment to Safety and Quality

  • At Fast Glass Processing ltd, we not only meet building regulations standards but also keep abreast of the latest independent reviews concerning building regulations and fire safety.
  • Our dedication to excellence drives us to go beyond compliance
  • We actively collaborate with our customers to tailor solutions that meet their specific project needs.
features-image
features-image-second
text-img

Our Philosophy

  • **Customer-Centric Approach**: We believe in going the extra mile to help you find the right solutions for your project, ensuring satisfaction at every step.
  • **Accreditation and Certification**: We prioritize obtaining relevant accreditations and certifications to demonstrate our commitment to providing the best possible products and services. These credentials assure our customers of our quality and reliability.

At Fast Glass Processing Ltd, our goal is to deliver not just products, but peace of mind through safety, compliance, and exceptional service. Let us assist you in achieving the highest standards for your project.



For the right specifications for your project, reach out to our team or complete the attached form. We are here to ensure you receive the correct quotes and solutions for your fire-rated glass needs. Trust Fast Glass Processing for quality, expertise, and customer satisfaction.
